ISO BS
链号 |
节距
|
滚子
直径 |
内节
内宽 |
销轴
直径 |
销轴
长度 |
连接销
轴长度 |
内链板
高度 |
排距
|
极限拉
伸载荷 |
平均拉
伸载荷 |
每米
重量 |
|
p
|
d1
|
b1
|
d2
|
L
|
Lc
|
h2
|
Pt
|
Q
|
Q
|
q
|
|
|
mm
|
mm
|
mm
|
mm
|
mm
|
mm
|
mm
|
mm
|
kN
|
kN
|
kg/m
|
|
|
06B-1
|
9.525
|
6.35
|
5.72
|
3.28
|
13.15
|
15.15
|
8.26
|
--
|
8.9
|
10.3
|
0.41
|
|
08B-1
|
12.7
|
8.51
|
7.75
|
4.45
|
16.95
|
19.05
|
11.81
|
--
|
17.8
|
19.6
|
0.69
|
|
10B-1
|
15.875
|
10.16
|
9.65
|
5.08
|
19.5
|
22.0
|
14.73
|
--
|
22.2
|
27.5
|
0.93
|
|
12B-1
|
19.05
|
12.07
|
11.68
|
5.72
|
22.5
|
25.1
|
16.13
|
--
|
28.9
|
33.3
|
1.15
|
|
16B-1
|
25.4
|
15.88
|
17.02
|
8.28
|
36.1
|
41.5
|
21.08
|
--
|
60.0
|
71.0
|
2.71
|
|
20B-1
|
31.75
|
19.05
|
19.58
|
10.19
|
42.4
|
47.6
|
26.42
|
--
|
95.0
|
101.8
|
3.70
|
|
24B-1
|
38.1
|
25.4
|
25.40
|
14.63
|
53.4
|
60.0
|
33.40
|
--
|
160.0
|
176.0
|
7.10
|
|
28B-1
|
44.45
|
27.94
|
30.99
|
15.9
|
65.1
|
72.5
|
37.08
|
--
|
200.0
|
215.6
|
8.50
|
|
32B-1
|
50.8
|
29.21
|
30.99
|
17.81
|
66.91
|
73.6
|
42.29
|
--
|
250.0
|
280.3
|
10.25
|
|
40B-1
|
63.5
|
39.37
|
38.10
|
22.89
|
82.6
|
91.3
|
52.96
|
--
|
355.0
|
392.0
|
16.35
|
|
48B-1
|
76.2
|
48.26
|
45.72
|
29.24
|
99.1
|
109.6
|
63.88
|
--
|
560.0
|
599.2
|
25.0
|
|
06B-2
|
9.525
|
6.35
|
5.72
|
3.28
|
23.4
|
27.1
|
8.26
|
10.24
|
16.9
|
18.1
|
0.74
|
|
08B-2
|
12.7
|
8.51
|
7.75
|
4.45
|
31.0
|
33.0
|
11.81
|
13.92
|
31.1
|
37.4
|
1.34
|
|
10B-2
|
15.875
|
10.16
|
9.65
|
5.08
|
36.1
|
38.6
|
14.73
|
16.59
|
44.5
|
54.2
|
1.84
|
|
12B-2
|
19.05
|
12.07
|
11.68
|
5.72
|
42.0
|
44.4
|
16.13
|
19.46
|
57.8
|
66.6
|
2.31
|
|
16B-2
|
25.4
|
15.88
|
17.02
|
8.28
|
68.0
|
73.4
|
21.08
|
31.88
|
106.0
|
126.5
|
5.42
|
|
20B-2
|
31.75
|
19.05
|
19.58
|
10.19
|
79.7
|
83.6
|
26.42
|
36.45
|
170.0
|
210.0
|
7.20
|
|
24B-2
|
38.1
|
25.4
|
25.40
|
14.63
|
101.8
|
108.4
|
33.40
|
48.36
|
280.0
|
305.0
|
13.4
|
|
28B-2
|
44.45
|
27.94
|
30.99
|
15.9
|
124.7
|
132.1
|
37.08
|
59.56
|
360.0
|
390.0
|
16.60
|
|
32B-2
|
50.8
|
29.21
|
30.99
|
17.81
|
125.46
|
132.4
|
42.29
|
58.55
|
450.0
|
487.5
|
21.0
|
|
40B-2
|
63.5
|
39.37
|
38.10
|
22.89
|
154.5
|
163.8
|
52.96
|
72.29
|
630.0
|
680.2
|
32.0
|
|
48B-2
|
76.2
|
48.26
|
45.72
|
29.24
|
190.4
|
200.9
|
63.88
|
91.21
|
1000.0
|
1070.0
|
50.0
|
|
06B-3
|
9.525
|
6.35
|
5.72
|
3.28
|
33.5
|
37.3
|
8.26
|
10.24
|
24.9
|
29.8
|
1.16
|
|
08B-3
|
12.7
|
8.51
|
7.75
|
4.45
|
44.9
|
47.2
|
11.81
|
13.92
|
44.5
|
50.2
|
2.03
|
|
10B-3
|
15.875
|
10.16
|
9.65
|
5.08
|
52.7
|
55.6
|
14.73
|
16.59
|
66.7
|
79.8
|
2.77
|
|
12B-3
|
19.05
|
12.07
|
11.68
|
5.72
|
61.5
|
65.2
|
16.13
|
19.46
|
86.7
|
101.8
|
3.46
|
|
16B-3
|
25.4
|
15.88
|
17.02
|
8.28
|
99.8
|
105.3
|
21.08
|
31.88
|
160.0
|
190.0
|
8.13
|
|
20B-3
|
31.75
|
19.05
|
19.58
|
10.19
|
114.55
|
121.2
|
26.42
|
36.45
|
250.0
|
276.2
|
10.82
|
|
24B-3
|
38.1
|
25.4
|
25.40
|
14.63
|
150.2
|
156.8
|
33.40
|
48.36
|
425.0
|
480.0
|
20.10
|
|
28B-3
|
44.45
|
27.94
|
30.99
|
15.9
|
184.3
|
191.7
|
37.08
|
59.56
|
530.0
|
580.0
|
24.92
|
|
32B-3
|
50.8
|
29.21
|
30.99
|
17.81
|
184.01
|
191.0
|
42.29
|
58.55
|
670.0
|
720.0
|
31.56
|
|
40B-3
|
63.5
|
39.37
|
38.10
|
22.89
|
226.8
|
236.1
|
52.96
|
72.29
|
950.0
|
1020.0
|
48.1
|
|
48B-3
|
76.2
|
48.26
|
45.72
|
29.24
|
281.6
|
292.2
|
63.88
|
91.21
|
1500.0
|
1590.0
|
75.0
|
